<div class="tt">IEC 62368-1:2023 (第四版) 标准发布 - 主要技术内容变更</div>
<div class="txt2 txtimg"><section><strong><span style="color: rgb(255, 0, 0);">2023年5月26日，国际电工委员会(IEC)发布了IEC 62368-1:2023 (第四版)标准；预计欧盟及北美地区将会6-12个月内首批发布对应的国家标准；建议制造商提前做好产品规划设计，以利于导入新标准的无缝衔接。</span></strong></section><p><br/></p><hr/><p><strong style="color: rgb(255, 0, 0);">新版标准与IEC62368-1:2018 (第三版)主要技术內容变更如下：</strong><br/></p><section></section><section></section><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>一.&nbsp;4.1.1章节 刪除 ”接受符合IEC 60950-1或IEC 60065的元器件和组件”</strong></span></p><p>意味着第四版不再接受IEC 60950-1和IEC 60065认证过的元器件或组件。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>二.&nbsp;4.1.8章节 更新了加压 LFC 测试G.15所适用的设备/组件</strong></span></p><p>删除”G.15 不适用于带有超过1L液体的设备”, 意味着超过1L液体的设备也需评估G.15</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>三.4.4.3.1章节 增加了热塑性材料(thermoplastic) T.8的测试要求</strong></span></p><p>作为安全防护的不可触及热塑性材料也需要做T.8的应力消除试验，例如 内部绝缘隔离用途的绝缘片。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>四.&nbsp;4.8章节 增加不适用含有纽扣电池设备类型以及警语要求</strong></span></p><p>更新了4.8章节不适用于纽扣电池不太可能会被小孩取出的设备，但是需要有的相关的电池警语(4.8.2)。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>五.&nbsp; 4.8.3章节 更新了对纽扣电池保护门或盖的结构设计要求</strong></span></p><p>4.8.3章节增加了多种可接受的结构设计类型。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>六.&nbsp; 4.10.3章节 增加了主电源线的要求</strong></span></p><p>明确了电源线只需要符合G.7电源线的要求，不需要把电源线当外部线来符合第六章的要求，特别是6.5章的外部线的防火要求。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>七. &nbsp;5.5.2.2章节 增加了工业设备的插头放电的要求</strong></span></p><p>增加了Pluggable equipment type B的工业设备的插头放电测试，放宽到5秒后才测可触及电压。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>八.&nbsp; 5.6.2.2章节 更新了接地导体的颜色要求</strong></span></p><p>明确了用于功能接地的导线不能使用黄绿颜色(线)，除非是多用途预装配部件。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>九. &nbsp;6.2.3.2章节 更新了电阻性PIS的测试方法</strong></span></p><p>简化了电阻性PIS的测试方法， 当使用control fire spread方法时， 除了二次锂电池外，在PS2电路中的零件和导体不认为是电阻性PIS，PS3电路里面都是电阻性PIS。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>十.&nbsp; 6.3.1章节 更新了防火外壳外部材料要求不适用的部件</strong></span></p><p>防火外壳外部材料要求不适用的部件中增加了loudspeaker drivers、网布、泡沫、栅格覆盖材料等。<br/>同时新增加了针对网布、泡沫、栅格覆盖材料需要符合附录S.6的相关试验(要求同于UL60065)。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>十一.&nbsp; 6.4.6章节 更新了控制PS3电路中的火焰蔓延的要求</strong></span></p><p>新增了对于压敏电阻与塑料外壳的距离小于13mm，压敏电阻需要符合G.8.2的要求，与外壳的防火等级无关。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>十二.&nbsp; 6.4.8.3.4章节 更新了防火外壳底部开孔的要求</strong></span></p><p>新增对于专业设备的周边环境不太可能有可燃材料的 (例如，在数据中心和服务器机房)，如果防火外壳底面符合6.4.8.3.4的要求，则扩展底面(Extended bottom surface)可视为如图44所示适用的防火外壳开孔要求。</p><p><img class="rich_pages wxw-img" src="https://mmbiz.qpic.cn/sz_mmbiz_png/GyF7ibkjqVn5ySAtWC7IO1dyXB0RShLMDZojj5ZWKia2luibcTMmTIOcC9YOcL3qgicPeeknaQN8w8MI9HFRgSRJmQ/640?wx_fmt=png&wxfrom=5&wx_lazy=1&wx_co=1" alt="图片" width="800" height="496" title="图片"/></p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>十三.&nbsp; 6.4.8.3.5章节 更新了防火外壳侧面开孔的要求</strong></span></p><p>新增对于防火外壳侧面厚度与开孔的关系，符合如图45所示的侧面开孔要求。</p><p><img class="rich_pages wxw-img" src="https://mmbiz.qpic.cn/sz_mmbiz_png/GyF7ibkjqVn5ySAtWC7IO1dyXB0RShLMDeeDLmCQdklwtAO7g2SRD0QhBLyCSHBKSYGA0iclA1OYp0dJPzLehmJg/640?wx_fmt=png&wxfrom=5&wx_lazy=1&wx_co=1" alt="图片" width="800" height="322" title="图片"/></p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>十四.&nbsp; P.2.1章节 更新了防异物外壳侧面开孔的要求</strong></span></p><p>新增对于防止异物进入的外壳侧面开孔尺寸符合如图P.3所示的要求，侧面开孔最大垂直高度小于11倍外壳侧面厚度。</p><p><img class="rich_pages wxw-img" src="https://mmbiz.qpic.cn/sz_mmbiz_png/GyF7ibkjqVn5ySAtWC7IO1dyXB0RShLMDQVFfDSdP3klOwAqqYLMlRGKj2ncuziaNHbfWqngGVFfS6IEayJIggSg/640?wx_fmt=png&wxfrom=5&wx_lazy=1&wx_co=1" alt="图片" width="800" height="630" title="图片"/></p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>十五.&nbsp; 9.6章节 更新了无线功率发射器的要求</strong></span></p><p>明确了无线功率发射器的测试要求只适用于平面的发射器，如果发射器不是平面的，例如有斜坡的，则该测试不适用。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>十六.&nbsp; 9.6.3章节 更新了测试方法和合格判据</strong></span></p><p>修改测试方法：1). 测试时的异物要有可靠的固定方式；2). 测试异物的4个周期分别做两次，第一次先让发射器工作再放异物，第二次先放异物再让发射器工作。</p><p>温度限制值放宽要求。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>十七.&nbsp; B.2.5章节 更新了输入测试的判定要求</strong></span></p><p>修改了对于非电网电源供电的设备的判定，要求输入测试的电流或功率不能大于设备的额定值。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>十八.&nbsp; F.3.5.3章节 更新了熔断器的标示要求</strong></span></p><p>明确了熔断器在何种情况需要指示性安全防护(instructional safeguard)以及指示性安全防护的标示要素。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>十九.&nbsp; F.3.6.2章节 更新了带有功能接地的II类设备的标示要求</strong></span></p><p>明确了哪些功能接地的II类设备需要标示功能接地符号 (IEC 60417-6092)。<br/></p><p><img class="rich_pages wxw-img" src="https://mmbiz.qpic.cn/sz_mmbiz_png/GyF7ibkjqVn5ySAtWC7IO1dyXB0RShLMDiamlMAicqVV8Z1aMczj4993c5wf75CLSKk4uIpTgTYEQJqM5OtApjJcg/640?wx_fmt=png&wxfrom=5&wx_lazy=1&wx_co=1" alt="图片"/></p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>二十.&nbsp; G.7.3章节 更新了不可拆卸软性的固定与应力消除的要求</strong></span></p><p>明确了ES2/ES3/PS3电路的互连线缆(interconnecting cable)也需要做软线应力消除的测试。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>二十一.&nbsp; G.15章节 更新了加压充液的元器件(LFC)的测试要求</strong></span></p><p>增加了加入了Self-contained LFC和modular LFC的要求以应对大于1升的液冷设备。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>二十二.&nbsp; M.4章节 更新了适用产品别</strong></span></p><p>删除”portable”(便携式设备)字眼，意味M.4的要求也适用于非portable的电池产品，适用的设备范围扩大了。</p><p>新增了带锂电池的驻立式设备stationary equipments时有额外的安全防护要求。</p><p><br/></p><p><span style="color: rgb(0, 112, 192);"><strong>二十三.&nbsp; M.4.3章节 更新了电池芯输出PS的测试要求</strong></span></p><p>明确了单电芯或组合电芯均需要评估PS能量源，输出PS1以下才可免除防火外壳。</p><p><br/></p></div>
